Operating Temp 60~100도/
Tolerance 5,7,10도/
Resetting Temp 46C or higher /
Maximum non-trip current
10A (Operating temp 75C Ambient 25C)
6A (Operating temp 80CΔT = 15K)
ΔT=Operating temp=Ambient temp /
Maximum cut-out current 120A 12VDC
