Technical characteristics

- Conformity to Community Directives: 2014/35/UE 2006/42/CE
- Conformity to Standards: EN 60204-1 EN 60204-32 EN 60947-1 EN 60947-5-1 EN 60529
- Regulations for the prevention of accidents BGV C 1 (only for Germany)
- CAN/CSA-C22.2 No 14-13
- UL 508
- IEC 61508:2010 Part 2-4-6-7
- Storage ambient temperature: -40°C/+80°C
- Operational ambient temperature: -40°C/+80°C
- Protection degree: IP 66 / IP 67 / IP 69K
- NEMA Protection degree: Type 4X*
- Insulation category: Class I
- Maximum rotation speed: 800 rev./min.
- Cable entry: Cable clamp M20
- Markings and homologations: CE cULus* SIL 1 EAC
